◆物料特別 Product features
1. 定制貼近生活,外型整齊,節能減排成果好;
2. 可調節式颶風分開器,能將可以選用金剛石工具與細微塵土分開,好的金剛石工具繼讀選用;
3. 包括零配件分為優秀國外進口鑄件,在使用保修期長;
4. 精加工產品工件界面平均;
5. 多治具設計的;進行運營者可一起進行運營噴砂。表明買家供需,先選擇人工機械或自動 ;可按朋友需求制作廠!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適用性依據 Applicable scope
木板材,計算機設備殼,影響表面板,漢堡包烤盤等立體圖及方體鏜孔的噴砂生產制作。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆基本技術水平基本參數 Main technical parameters
絲機型號規格 Model |
STR-多工位輸送式噴砂機 |
整個機械尺寸 Complete machine size(mm) |
3000×1000×1700 |
運行空間 Work space(mm) |
2000×1000×800 |
外卸料面積 Conveying the size(mm) |
500×1000×1000(2件) |
除塵處理箱尺寸規格 Dedust box sizes(mm) |
600×600×1800 |
隔離器直流電機 Separator motor |
220V 50HZ 550W |
區分器風口尺寸 Separator air volume |
8.5m3/min |
進行壓縮氣體源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W防火燈 |
器機毛重 Machine weight |
550kg |
